Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact

Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact

Large Image :  Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact

Product Details:
Place of Origin: CHINA
Brand Name: XIN CHENG LAIGANG XINYU LIANGANG
Certification: AISI ASTM
Model Number: NM 360 NM 40 NM 450 NM 500 NM500 wear Plate 400 NM500 wear Plate 450 NM500 wear Plate 5000
Payment & Shipping Terms:
Minimum Order Quantity: 3Ton
Price: USD 600-700 Per ton
Packaging Details: Waterproof paper, and steel strip packed. Standard Export Seaworthy Package.Suit for all kinds of transport,or as required. Port Qingdao port , Tianjin port , Shanghai port
Delivery Time: 7days
Payment Terms: L/C, T/T
Supply Ability: 300000 per year
Contact Now

Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact

Description
Name: Wear Resistant Steel Plate Package: Standard
Technique: Hot Rolled Grade: NM500 Wear Plate 400 NM500 Wear Plate 450 NM500 Wear Plate 500 NM500 Wear Plate550
Size: Standard Or Customized Application: Mining Machinery ,enviromental Protection Machinery .
Highlight:

Steel Wear Plate NM500 wear Plate 400

,

Steel Wear Plate NM 450

Fast delivery Wear Resistant Steel Plate NM 450 NM 500 High Impact



​Product Description

Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 0
SPECIFICATIONS FOR Wear Resistant Steel Plate/Sheet
Product Name
hot rolled wear steel ar400 ar500 nm400 nm500 wearing resistant steel plate
Standard
AISI,ASTM, EN, BS, GB, DIN, JIS





Materials
NM360,NM360L,NM400,NM400L,NM400A,NM450,NM450L,NM450A,NM500A.NM550,NM600.
NR360,NR400,MITTA 400F,MITTA 450F,MITTA 500F
DILLIDUR400,DILLIDUR500,DILLIDUR400V,DILLIDUR500V,DILLIDUR450V
QUARD400,QUARD450,QUARD500
FORA400,FORA500,CREUSABRO4800,CREUSABRO8000
RAEX400,RAEX450,RAEX500
Inspection
ISO,BV,SGS,MTC
Packing
Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
Supply Ability
250000 metric tons/Year
MOQ
5 metric ton,sample order accepted
Shipment time
Within 7-10 workdays after receiving deposit or L/C
Payments
T/T,LC
Chemical Content
Steel/Grade
C
Si
Mn
P
S
AL
Cr+Ni+Mo
Nb+V+Ti
NM360/AR360
0.10-0.30
0.20-0.40
1.00-2.00
≤0.015
≤0.003
≥0.20
<0.6




Trace Amount
NM400/AR400
0.10-0.40
0.20-0.40
1.00-2.00
≤0.015
≤0.003
≥0.20
<0.9
NM450/AR450
0.10-0.40
0.20-0.40
1.00-2.00
≤0.015
≤0.003
≥0.20
<1.2
NM500/AR500
0.10-0.40
0.20-0.45
1.00-2.00
≤0.015
≤0.003
≥0.20
<1.5
NM550/AR550
0.10-0.50
0.20-0.45
1.00-1.50
≤0.015
≤0.003
≥0.20
<2.0
NM600/AR600
0.10-0.50
0.20-0.45
1.00-1.50
≤0.015
≤0.003
≥0.20
<2.5
Mechanical property

Grade
Tensile strength
Elongation
Hardness
-20℃ Impact energy
(Mpa)
(%)(min)
(HBW)
AKv/J (min)
NM360
≥1100
12
330-390
24
NM400
≥1200
10
370-430
24
NM450
≥1250
7
420-480
24
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 1
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 2
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 3
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 4
Packing & Delivery

Kunda Steel usual packing by waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
1) 20ft container: 26tons
(Can load 5.8M Max)
2) 40ft container: 26tons
(Can load 11.8M Max)
3) more than 100tons:
can pack by bulk vessel
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 5
Application Show
Wear resistant steel with 2 to 12mm in thickness are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outstanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality. Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc.
(1) engineering machinery and equipment: loaders, bulldozers, excavators
(2) handling machinery and equipment: unloading mill chain plate, hopper liner, grab the edge plate, and automatic
tipper tipping plate
(3) of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board.
Dust collector liner
(4) metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner,
scraper machine liner
(5) mining machinery and equipment: aggregate, stone crusher liner, blade
(6) Other mechanical equipment: sand barrel, blade, a variety of port machinery wear part
(7) of thermal power equipment: coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading
equipment lining plate
(8) shot blasting machinery: shot blasting machine lining board.
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 6
Customer Visit
With Concept of "Keep Improving,Win-win Cooperation",and executed by reliable quality and after sales service system,Kunda gained good reputation from customers at home and abroad.We sincerely welcome you come to our company negotiate business and make great achievement together !
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 7
Company Profie
Shandong Kunda Steel Co.,Ltd. Located in Liaocheng city,Shandong province,which is a picturesque city be crowned as"the Oriental Venice".Liaocheng in the west of Shandong province,200Km South from Beijing City,100Km west from Jinan City.Jiqing Expressway cross the city from East to West;Beijing-Kowloon Railway runs though North to South,benefit from the convenient traffic condition Liaocheng economy develops rapidly and formed the largest steel logistics centre in North China.
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 8
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 9
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 10

​



Customer Visit
With Concept of "Keep Improving,Win-win Cooperation",and executed by reliable quality and after sales service system,Kunda gained good reputation from customers at home and abroad.We sincerely welcome you come to our company negotiate business and make great achievement together !
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 7
Company Profie
Shandong Kunda Steel Co.,Ltd. Located in Liaocheng city,Shandong province,which is a picturesque city be crowned as"the Oriental Venice".Liaocheng in the west of Shandong province,200Km South from Beijing City,100Km west from Jinan City.Jiqing Expressway cross the city from East to West;Beijing-Kowloon Railway runs though North to South,benefit from the convenient traffic condition Liaocheng economy develops rapidly and formed the largest steel logistics centre in North China.
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 8
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 9
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 10
Certifications
Kunda Steel is a subsidiary of Laiwu Steel Mill Plant, founded in 2010 and engaged in production and sales of Wear Resistant Steel Plate/Weathering Steel Plate/High Strength Carbon Steel Plate/Stainless Steel/Aluminum&Brass and Sectional materials.Kunda operation more than 15000square meters space,existing staff 200 workers,including 12 technical specialists,we passed Certificate ISO9001 / ISO14000 / OHSAS18001.As a member of China iron and steel association,we established long term friendly cooperation with famous domestic mill plants,such as Baosteel/Wusteel/Ansteel/Taisteel etc.As well as actively pursues partnerships with SSAB and POSCO,in order to meet customer requirement.
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 15
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 16
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 17
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 18
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 19
Hot Rolled Steel Wear Plate NM500 wear Plate 400 NM 450 NM 500 High Impact 20
